CH0470T 10x100
Back to products
CH0570 10X100

CH0500 10×100

144×119 mm

131×107 mm

108×84 mm

45 mm

55 mm

500 cc

Download Technical Sheet
  • Technical Sheet
  • Downloads

Technical Sheet

EAN code Bag 5410797300125
EAN code cart./Technifi 5410797300118
EAN code Palet
Volume 500 cc
Top out 144×119 mm
Top in 131×107 mm
Base 108×84 mm
Useful Height 45 mm
Total Height 55 mm
Net Weight 6,95 gr
Model CH (2)
Gauge 58 µ
Alloy (*0) 8006 H24 (0)
Lubrication (1)
Holes NO
Diameter
Colors in/out ALU/ALU
Rolled edge 2,2 mm
Temperature -40°C-350°C
#Pcs pro carton: 1000
#Pcs pro bag 100
#Bags pro carton 10
#Cartons pro palette 32
#Cartons pro layer 4
#Layers Pro palette 8
#Pcs pro palette 32000
Carton dimension L.D.H 490x400x261mm
Tare carton (kg) 0,54
Net carton (kg) 6,95
Gross carton (kg) 7,49
Gross palette (kg) 269,68
Palette height (meter) 2,28
Country of Production Belgium

Downloads

Download Technical Sheet CH0500 10×100
Declaration of Conformity (DoC) Aluminium Foil Containers
