CH3200 4X100
Back to products
CR0150 28X100

CR0140 15X100

102×67 mm

93×56 mm

80×43 mm

33 mm

37 mm

140 cc

Download Technical Sheet
  • Technical Sheet
  • Downloads

Technical Sheet

EAN code Bag 5410797201026
EAN code cart./Technifi 5410797201019
EAN code Palet
Volume 140 cc
Top out 102×67 mm
Top in 93×56 mm
Base 80×43 mm
Useful Height 33 mm
Total Height 37 mm
Net Weight 2,88 gr
Model CR (3)
Gauge 55 µ
Alloy (*0) 8006 H24 (0)
Lubrication (1)
Holes NO
Diameter
Colors in/out ALU/ALU
Rolled edge 2,2 mm
Temperature -40°C-350°C
#Pcs pro carton: 1500
#Pcs pro bag 100
#Bags pro carton 15
#Cartons pro palette 50
#Cartons pro layer 4 + 2R
#Layers Pro palette 10 + 5
#Pcs pro palette 75000
Carton dimension L.D.H 457x392x212mm
Tare carton (kg) 0,44
Net carton (kg) 4,32
Gross carton (kg) 4,76
Gross palette (kg) 268
Palette height (meter) 2,41
Country of Production Belgium

Downloads

Download Technical Sheet CR0140 15X100
Declaration of Conformity (DoC) Aluminium Foil Containers
