WC1000 330
Back to products
WC1442 6X50

WC1170 280

265×162 mm

247×144 mm

234×13 mm

36 mm

36 mm

1168 cc

Download Technical Sheet
  • Technical Sheet
  • Downloads

Technical Sheet

EAN code Bag
EAN code cart./Technifi 5410797911109
EAN code Palet
Volume 1168 cc
Top out 265×162 mm
Top in 247×144 mm
Base 234×13 mm
Useful Height 36 mm
Total Height 36 mm
Net Weight 18,88 gr
Model W(7)
Gauge 105 µ
Alloy (*0) 8006/H23 (0)
Lubrication (1)
Holes NO
Diameter
Colors in/out ALU/ALU
Rolled edge 2,2 mm
Temperature -40°C-350°C
#Pcs pro carton: 280
#Pcs pro bag 280
#Bags pro carton 1
#Cartons pro palette 48
#Cartons pro layer 8
#Layers Pro palette 6
#Pcs pro palette 13440
Carton dimension L.D.H 401X301X316mm
Tare carton (kg) 0,5
Net carton (kg) 5,2864
Gross carton (kg) 5,7864
Gross palette (kg) 307,7472
Palette height (meter) 2,04
Country of Production Europe

Downloads

Download Technical Sheet WC1170 280
Declaration of Conformity (DoC) Aluminium Foil Containers
