S45 75
Back to products
S55 50

S55 10X5

550×362 mm

520×337 mm

416×433 mm

21 mm

29 mm

2380 cc

Download Technical Sheet
  • Technical Sheet
  • Downloads

Technical Sheet

EAN code Bag 5410797505568
EAN code cart./Technifi 5410797505551
EAN code Palet
Volume 2380 cc
Top out 550×362 mm
Top in 520×337 mm
Base 416×433 mm
Useful Height 21 mm
Total Height 29 mm
Net Weight 82,21 gr
Model S (8)
Gauge 145 µ
Alloy (*0) 8665 H21/8006 H0/3005 H0 (0)
Lubrication (1)
Holes NO
Diameter
Colors in/out ALU/ALU
Rolled edge 4,6 mm
Temperature -40°C-350°C
#Pcs pro carton: 50
#Pcs pro bag 5
#Bags pro carton 10
#Cartons pro palette 32
#Cartons pro layer 4
#Layers Pro palette 8
#Pcs pro palette 1600
Carton dimension L.D.H 565x375x245mm
Tare carton (kg) 0,673
Net carton (kg) 4,1105
Gross carton (kg) 4,7835
Gross palette (kg) 183,072
Palette height (meter) 2,14
Country of Production Belgium

Downloads

Download Technical Sheet S55 10X5
Declaration of Conformity (DoC) Aluminium Foil Containers
