SP125P 1260
Back to products
SP175 1200

SP125P 12X100

185X115 mm

170×100 mm

155×90 mm

8 mm

11 mm

125 cc

Download Technical Sheet
  • Technical Sheet
  • Downloads

Technical Sheet

EAN code Bag 5410797620124
EAN code cart./Technifi 5410797620117
EAN code Palet
Volume 125 cc
Top out 185X115 mm
Top in 170×100 mm
Base 155×90 mm
Useful Height 8 mm
Total Height 11 mm
Net Weight 9,34 gr
Model S (8)
Gauge 78 µ
Alloy (*0) 8906-0/8666 H25/8156 H24/8006 H24 (0)
Lubrication (1)
Holes NO
Diameter
Colors in/out ALU/ALU
Rolled edge 2,6 mm
Temperature -40°C-350°C
#Pcs pro carton: 1200
#Pcs pro bag 100
#Bags pro carton 12
#Cartons pro palette 24
#Cartons pro layer 4
#Layers Pro palette 6
#Pcs pro palette 28800
Carton dimension L.D.H 590x390x350mm
Tare carton (kg) 0,96
Net carton (kg) 11,208
Gross carton (kg) 12,168
Gross palette (kg) 322,032
Palette height (meter) 2,31
Country of Production Europe

Downloads

Download Technical Sheet SP125P 12X100
Declaration of Conformity (DoC) Aluminium Foil Containers
